WPM - Repeater 2480.00.91 .43 WPM - Repeater 2480.00.91 .43 WPM - Repeater 2480.00.91 .43 MAIN CATALOG Boosting your production Standardized products, individual customizations and tailor-made solutions
2 With us you get far more than just products. We optimise your manufacturing with customized solutions, expert advice and comprehensive services. Customer-oriented, open and dynamic: FIBRO, as part of the LÄPPLE Group, brings you not only the perfect product – but the combined force of a strong corporate group. Together we offer you worldwide solutions that exceed your expectations.
3 Data & Facts 1.000.000 Employees worldwide Our talented staff work around the globe to create genuine added value. Products in the range A comprehensive offering to meet any challenge – always the right solution available. 40.000 Products in stock High availability guarantees short delivery times and maximum flexibility – worldwide. 5 Certifications A responsible approach to using resources, protecting the environment and ensuring quality is deeply rooted in our company policy. 91 million euros of turnover in 2025 Our continuous growth speaks to the quality and innovative strength of our products. 17 Patents Our pioneering ideas secure us the technological advantage. 600
4 Always within reach Our company is deeply rooted in its local region and operates internationally – on-site for you, worldwide. Our production sites, subsidiaries and sales agencies guarantee that we keep our promise: proximity and support, wherever you need us. With our international focus, we offer you personal support in the global production environment at all times. Worldwide for you on site
5 FIBRO GmbH Haßmersheim, Germany FIBRO FRANCE Schiltigheim, France FIBRO INDIA Pune, India OMCR SRL. San Maurizio, Italy FIBRO ASIA SDN BHD Petaling Jaya, Malaysia FIBRO POLSKA Bielsko-Biala, Poland LAEPPLE TAICANG Taicang, China FIBRO INC Detroit, USA FIBRO KOREA CO. LTD Bucheon, Korea Headquarters • Locations • Dealerships
6 Solutions for every need Guiding Shaping Springs Punching
7 In addition to a wide range of standard products, FIBRO also offers custom solutions that are individually tailored to the needs of our customers. Customisation requests can be easily implemented after consultation with our product experts. Thanks to modern production facilities, we realise specific requirements flexibly, achieving the optimal results for you. Are you looking for a customised solution not available among our standard products? At FIBRO, we offer the option to manufacture products entirely according to your specifications. Our employees are with you every step of the way and work closely with you to individualise the design and layout of components. This is how we find the perfect solution that is precisely tailored to your requirements. Standard to your measurements Custom-made to your specification FIBRO customers benefit from over 1,000,000 standard products that have been developed for a variety of common applications. Our employees will help you make the right choice for your specific use case. Various selection wizards and configurators are also available to ensure that you always find the optimal solution for your requirements. A B C Standard according to catalogue
8 Guides for versatile blister packaging machines Due to the minimal clearance between punch and die, our guide elements offer the most efficient solution. Our guides are used in interchangeable punching tools on blister packaging machines enabling different punching variants for a wide variety of silver strips. Perfect diamonds thanks to precise guide elementsGuides for versatile blister packaging machines With our guide unit, the diamond is positioned and held securely during micro-polishing. Customer-specific pillars, bushes and ball cages are used to guarantee maximum accuracy and efficiency. These tailor-made components optimise the polishing process and ensure perfect results.. Million Guide Performance at the limit The „Million Guide" defines the maximum level for guide units. It offers the highest accuracy level in guidance and repeatability, as well as high dynamic load ratings, even at the highest lifting speeds. This increases the productivity and performance of your tools and machines, and saves costs in the long term. Guide elements + Die sets + Precision machined plates and flat bars + Chemistry Guide elements are crucial in tool and mechanical engineering for guiding and controlling movements and forces. Our wide range provides the option to select the optimal components for your machines and applications. This means you can achieve the best results even under harsh environmental conditions or in high-precision applications. Guiding
9 More automation in office furniture manufacturing Adding threads to thousands of thick sheet metal parts is a challenge. It becomes even trickier when tight cycle times have to be adhered to and there is a lack of space in the die. By using our electronic thread forming unit (FETU), the process has been successfully automated and productivity targets were actually exceeded. Gas springs New generation with improved performance FIBRO gas springs can be used in a wide variety of applications – from forming to cutting or punching. Thanks to safety features such as overpressure, overstroke and return stroke protection, they offer maximum safety for people and tools and comply with VDI 3003 and 3004 and ISO 11901 standards. The patented Wireless Pressure Monitoring System (WPM) monitors the pressure and temperature of springs wirelessly, permitting preventive maintenance, high process reliability, and less maintenance work. Also new is a preconfigured starter kit that offers easy integration and local monitoring via Bluetooth, entirely without cables. Springs + Elastomers + Cam Units + Die sets + tapping unit + Lifting and clamping devices Shaping Production of washing machine side parts For manufacturing side parts of washing machines, which are produced in very high quantities, durable FIBRO gas springs are used in the forming process to ensure trouble-free, efficient production. From body panels to white goods, to housing components or furniture fittings – our extensive product portfolio means we offer the right product for a wide variety of forming techniques. Whether in the automotive industry or in precision engineering: bank on efficiency and precision to take your production to the next level.
10 Improved power transmission with minimal space requirements The use of FIBRO gas springs in the plastic injection moulding of control knobs, handles and air conditioning ducts allows higher constant forces to be implemented in the smallest space, reduces maintenance costs and significantly increases product quality. Elastomers The universal product Our FIBROFLEX elastomers offer the widest range of options: from forming to cutting, bending, embossing, stripping, ejecting, absorbing or as part protection. The areas of application are wide-ranging and are particularly suitable for small quantities as a cost-effective solution as no complex tools are required. Springs + Elastomers Our broad range of spring elements includes gas springs, elastomer springs, compression springs, spring plungers and more. From traditional toolmaking to machine and fixture construction, our springs are utilised in a wide variety of applications. Springs FIBROFLEX replaces mechanical springs in small aircraft FIBROFLEX are used in small aircraft to reduce the weight. These innovative shock absorbers replace conventional mechanical springs, enabling a significant reduction in weight.
11 With punching needles for perfect spatial sound Perforating wood is a demanding task because the material is thin and must be processed without lubricants to ensure adhesion of glue and coating. This challenge was addressed by FIBRO by optimising the geometry of the punching needles. Efficiency and precision makes punching an indispensable process in many industries. Using punches and dies, both flat and shaped parts can be produced. Electric transporters provides a reliable and automated part transport. Thread formed at 150 strokes/min Integrating the FETU thread tapping unit into the punching and forming process achieved an increase in the production output of sockets of around 50%. The solution deployed here was a custom solution rather than a standard one. Integrated process monitoring also contributes to increasing product quality. Safe removal of clips From airbags to panels – vehicle manufacturers rely on clips for fastenings, manufactured as stamped and bent parts. The variety of part sizes and the light weights make outward transport difficult. Our electric transporter was used here and ensures trouble-free transport. Punching Precision components + Elastomers + Transporters & conveyor belts + Die sets + tapping unit + Cam Units + Lifting and clamping devices Electric transporters Quiet, efficient, sustainable Electric transporters impress with their cost-effectiveness and flexibility. With low energy consumption, they offer a cost-effective solution for transport tasks such as sorting, organising, positioning or feeding and discharging components. Parts are transported by individually configurable transport channels available in a wide variety of materials. In addition, transporters offer the benefits of low noise (60 dB), the absence of compressed air, easy automation and virtually maintenance-free operation. They are versatile, both in the metalworking and automotive industries as well as in the "Clean Line" version for the food and pharmaceutical industries.
12 fibro.partcommunity.com www.fibro.com All products can be found online
13 Simple. Direct. FIBRO. Welcome to our new online platform – for technical professionals and quick decision-makers. Improved user guidance All information, products, and services clearly bundled Fast quotation Your quotation for stock items is usually received within 45 minutes Direct price and availability query You can see prices and stock levels directly online Quick order function Order multiple articles quickly and easily in just a few steps Excel upload Import large orders conveniently via Excel file Third-party article number search Easily convert competitors' articles into FIBRO articles Access to the 3D CAD database Direct download of CAD models for design work Live chat Direct line to the FIBRO team if you have any questions or need advice
14 Our systems can be individually adapted to your specific requirements with various configurations – for maximum flexibility in operation. The maintenance-friendly construction keeps the maintenance requirements to a minimum – this saves time and lowers the operating costs long-term. All components are made from particularly wear-resistant or hardened steels – for maximum capacity and a long life. Your direct contact is by your side for consultation from planning and commissioning to trainings and during running operation – for quick solutions and individual support. Making more from chips: Economical, compact, environmentally friendly. High-performance briquetting machines Utilise the full potential of your manufacturing process.
15 Gas springs with two connection solutions – for maximum flexibility and easy integration into your tooling concept.Gas springs for composite plate systems with two connection options - with the FIBRO composite plate system, you benefit from a unique combination and the answer to your flexibility requirements. Two connection options in one product Easy integration into existing tools Unique on the market We supply Punches with countersunk head or cylindrical head according to DIN / ISO and other standards, as well as Ball-Lock punches and ejector pins. Fast and reliable – even in large quantities. The continuous quality monitoring of our standard parts production – from material receipt to the end product – results in exceptionally long service life of our punches and thus in increased cost-effectiveness in your stamping shop. Composite plate systems A Gas Spring. Two Connection Options. Punch More cost-effectiveness for your stamping shop
16 Many years of experience Our decades of experience in toolmaking form the basis for Guide elements that combine precision, stability, and durability. Through deep technical expertise and continuous further development, we deliver solutions that perform reliably even under the most demanding conditions. Thanks to large inventories, we ensure maximum delivery capability – quickly, reliably and predictably. Customizing in-house – even the largest diameters Custom instead of standard: Our in-house production realizes your customer-specific requirements with maximum precision – XXL on request. Individual guide elements Quick availability Thanks to large stock inventories, we ensure maximum delivery capability – fast, reliable, and plannable. Individual instead of standard: Our in-house production realises your customer-specific requirements with maximum precision – even XXL on request. Optimal pairing – optimal tool guidance Perfectly paired: With our three different pairing classes .10 / .20 / .30, you can optimize the lead clearance for sliding guides or preload for ball bearings – for maximum precision with every stroke with minimal wear. Our FIBROFLEX® elastomers offer the widest range of possibilities: from forming to cutting, bending, embossing, stripping, ejecting, damping, or as part protection and much more. Our product portfolio includes plates, tubes, and profiles; in addition, we offer raw material for in-house machining, custom-cut pieces, cast mouldings, as well as complex part production. FIBROFLEX® The solution for every form and function
17 Hot Forming One Stop Solution FETU Electronic thread tapping Quality Products with high temperature resistance, long service life and zero leakage – for optimum performance in demanding applications. Cost We combine the best price with the highest quality and offer cost-efficient and high-performance solutions without compromising on excellence. Time Stock availability for standard parts as well as shipping within 3 to 7 days – for speed and efficiency with every order. Variety Holistic solutions for hot forming that cover all requirements in a single step. Service Extensive experience and sound technical advice to support you at every stage of the process. Versatile and flexible application Autonomous system wide range of thread sizes from M0.8 to M20, additional sizes available on request simple programming and control integrated process monitoring Cost-effectiveness through multiple use Cost savings through high forming speed a high level of investment security
18 precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard
19 precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard precision is our standard
A B C D E F G H J K L Precision ground plates and flat bars Lifting and clamping devices Guide elements Ground precision components Springs Elastomers Chemical tooling aids Cam units Standard parts for mould making Die sets Peripheral equipment Cast iron, steel and aluminium Die set press units, lamination die set units, tooling pallet die sets
A2 Die sets Further information at
A3 subject to alterations Die sets Execution The contour faces of FIBRO Steel Die Sets are fully machined. Contour faces of Aluminium Die Sets are sawn, as are those of Aluminium Plates. However, these contour faces can also be machined on request. Plate thickness tolerance ± 2 mm. Lifting Aids on Die Sets For a plate dimension of a1+b1≧1000 mm and a plate weight of ≧100 kg, 2 lifter eyebolts per plate are to be used. Guide elements Guide pillars DIN 9825/ISO 9182 (202.19.) and headed guide bushes DIN 9831/ISO 9448 (2081.) are normal equipment on all-steel die sets. Please see the "Guide elements" section for technical specifications. Addition of the article number for guide post frame with guide pillar type/length With the following letter combinations, the guide pillar type/length can be specified for pillar frames. These are to be added at the end of the article number. (Order example, see beginning of chapter cast pillar frames and steel and aluminum pillar frames) Length Guide pillar 202.19. 100 AA 112 AB 125 AC 140 AD 160 AE 180 AF 200 AG 224 AH 250 AJ 280 AK 315 AL 355 AM 400 AN 450 AO 500 AP 550 AQ 600 AR 700 AS 800 AT The instructions on the guide column for the products are to be observed. Other lengths on request! Special Die Sets and Plates to Customers’ Drawings Die sets and plates up to size 2200 x 1100 mm (external dims.) will be made to customer’s drawings, with any special features and highest precision. Special Machining Features Wherever possible, all larger apertures or holes should be done by FIBRO before final machining of die sets, for their application at the customer’s works must result in die set distortion and impairment of accuracy. Enquiry Forms for Special Die Sets (see also pages A32 – A35) For custom sizes and special versions, pre-printed enquiry and order forms are available on request. All you need to do is enter your desired measurements, custom designs and the guide type.
A4 A7-22 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A24-31 A32 Contents subject to alterations Cast iron die sets 201.01. Die set DIN 9812 Type D/DG 201.03. Die set DIN 9814 Shape D/DG 201.05. Die set DIN 9816 Shape D 201.07. Die set ~DIN 9816 Shape D 201.11. Die set DIN 9812 Shape C/CG 201.13. Die set DIN 9814 Shape C/CG 201.21. Die set DIN 9819 Shape C/CG 201.23. Die set 201.26. Die set 201.31. Die set DIN 9822 Shape C 201.33. Die set 201.36. Die set 201.39. Fine blanking die set 2010. Die set ~DIN 9868/ISO 11415 201.45. Die set to customer specifications in steel
A5 A32 A33 A33 A34 A34 A35 A35 A36-37 A36-37 A36-37 A38 A39 A40 A41 A42 A42 Contents subject to alterations 201.65. Die set to customer specifications in aluminium 201.46. Die set to customer specifications in steel 201.66. Die set to customer specifications in aluminium 201.47. Die set to customer specifications in steel 201.67. Die set to customer specifications in aluminium 201.69. Die set to customer specifications in aluminium 201.49. Die set to customer specifications in steel 2010.55. Die set ECO-LINE 2010.57 Die set ECO-LINE 2010.59. Die set ECO-LINE 2900. Steel plate ISO 6753-1 2910. Aluminium plate ~ISO 6753-1 2011.4x. Die set press unit 201.14x. Die set press unit, manual actuation Die Set Press Unit-Accessories: 212.16.1 Spigot holder
A6 A42 A42 A43-46 A47-52 A50 A51 A52 Contents VXEMHFW WR DOWHUDWLRQV 212.11. Coupling spigot with thread 212.15. Coupling spigot with flange Special Die Set (All-Steel) to Customers‘ Specification Progression lamination die set units 201.50.xx20. Progression lamination die set unit 201.50.xx25. Progression lamination die set unit 201.50.xx30. Progression lamination die set unit
A7 subject to alterations Cast iron die sets
A8 201.13.125.100.034.AF 201.03.100.034.AF 201.13.125.100.041.AF subject to alterations Cast iron die sets - Order samples Guide pillar type/length = 180 mm (AF) Order number part 2, without die riser and with pin thread in the upper part (1) Order number part 2, Guide type: Roller bearing without die riser (04) Order number part 1, Working area width b1 = 100 mm (100) Order number part 1, Working area length a1 = 125 mm (125) Type/Standard: DIN 9814 Shape C/CG (13) Die set (201) Ordering Code (example): Note: See table for standard dimensions Special dimensions available on request Die set Order number part 1 depending on the type/standard of the pillar frame Working surface a1 x b1 Working area length a1 = 125 mm Working area width b1 = 100 mm Working surface d1 Order number part 2 depending on the type/standard of the pillar frame Guide type Order No Sinter guide without/with die riser = 03 Roller bearing without die riser = 04 Roller bearing with die riser = 05 Order number part 2 depending on the type/standard of the pillar frame Guide type Order No without die riser and without pin thread = 0 without die riser and with pin thread = 1 with die riser and without pin thread = 4 with die riser and with pin thread = 5 in the upper part Guide pillar type/length = 180 mm (AF) Order number part 2, with die riser and without pin thread in the upper part (4) Order number part 2, Guide type: Sintered ferrite (03) Order number part 1, Working surface d1 = ø 100 mm (100) Type/Standard: DIN 9814 Shape D/DG (03) Die set (201) Ordering Code (example): Type/Standard: Order No DIN 9812 Shape D/DG = 01 DIN 9814 Shape D/DG = 03 DIN 9816 Shape D = 05 ~DIN 9816 Shape D = 07 DIN 9812 Shape C/CG = 11 DIN 9814 Shape C/CG = 13 DIN 9819 Shape C/CG = 21 FIBRO-Standard = 23 FIBRO-Standard = 26 DIN 9822 Shape C = 31 FIBRO-Standard = 33 FIBRO-Standard = 36 FIBRO-Standard = 39 Length Guide pillar 202.19. 100 = AA 112 = AB 125 = AC 140 = AD 160 = AE 180 = AF 200 = AG 224 = AH 250 = AJ 280 = AK 315 = AL 355 = AM 400 = AN 450 = AO 500 = AP 550 = AQ 600 = AR 700 = AS 800 = AT
A9
A10 subject to alterations Die set DIN 9812 Type D/DG M .030 .040 .031 M .041 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Available without or with shank thread in top bolster b2 c7 c1 c3 d3 e a2 d1 f d2 c2 l r A A B B 201.01. Section A - A Section B - B Work area Order No part 1* d1 a2 b2 c1 c2 c3 c7 d2 d3 e f l r M 201.01.063.□□□.□□ 63 182 100 40 25 60 20 16 15 106 73 140 - 355 20 16x1,5 201.01.080.□□□.□□ 80 236 120 50 30 80 30 20 19 140 90 160 - 400 28 20x1,5 201.01.100.□□□.□□ 100 275 140 50 30 80 30 25 24 165 110 160 - 500 35 20x1,5 201.01.125.□□□.□□ 125 300 165 50 30 80 30 25 24 190 139 160 - 500 35 20x1,5 201.01.160.□□□.□□ 160 360 200 56 40 90 30 32 30 240 174 180 - 500 40 24x1,5 201.01.180.□□□.□□ 180 380 220 56 40 90 30 32 30 260 194 180 -500 40 24x1,5 201.01.200.□□□.□□ 200 400 240 56 40 90 30 32 30 280 218 180 - 500 40 24x1,5 201.01.250.□□□.□□ 250 496 300 56 50 100 30 40 38 350 268 200 - 800 48 30x2 201.01.315.□□□.□□ 315 563 365 63 50 100 30 40 38 417 333 224 - 800 48 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.01. Die set DIN 9812 Type D/DG
A11 subject to alterations B A B 45° c8 c4 l c1 c3 c2 b2 a2 d1 e f d3 d2 c7 A r 201.03. Section A - A Section B - B Die set DIN 9814 Shape D/DG M .034 .054 .035 M .055 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Stripper Steel Steel Order No (part 2) Available without or with shank thread in top bolster Work area Order No part 1* d1 a2 b2 c1 c2 c3 c4 c7 c8 d2 d3 e f l r M 201.03.100.□□□.□□ 100 275 140 50 30 50 22 30 18 25 24 165 119 160 - 500 35 20x1.5 201.03.125.□□□.□□ 125 300 165 50 30 50 22 30 18 25 24 190 144 160 - 500 35 20x1.5 201.03.160.□□□.□□ 160 360 200 56 40 60 27 30 18 32 30 240 184 180 - 500 40 24x1.5 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.03. Die set DIN 9814 Shape D/DG
A12 subject to alterations Die set DIN 9816 Shape D .030 .040 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Without shank thread in top bolster b2 c7 c1 c2 d e a2 d1 d2 l r A A B B 3 201.05. Section A - A Section B - B Work area Order No part 1* d1 a2 b2 c1 c2 c7 d2 d3 e l r 201.05.063.□□□.□□ 63 182 100 40 65 20 16 15 106 140 - 355 20 201.05.080.□□□.□□ 80 236 120 50 70 30 20 19 140 160 - 400 28 201.05.100.□□□.□□ 100 275 140 50 75 30 25 24 165 180 - 500 35 201.05.125.□□□.□□ 125 300 165 50 80 30 25 24 190 180 - 500 35 201.05.160.□□□.□□ 160 360 200 56 90 30 32 30 240 224 - 500 40 201.05.200.□□□.□□ 200 400 240 56 100 30 32 30 280 224 - 500 40 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.05. Die set DIN 9816 Shape D
A13 subject to alterations b2 b1 20 c1 c2 d3 d1 a2 e B A B A d2 l r 201.07. Section A - A Section B - B Die set ~DIN 9816 Shape D Guide Elements Sintered Ferrite Guide Bushes Work area Order No d1 a2 b1 b2 c1 c2 d2 d3 e l r 201.07.040.030.□□ 40 112 45 55 36 40 16 15 66 100 - 355 13 201.07.063.030.□□ 63 142 68 78 40 55 16 15 90 125 - 355 14 *Order number part 2 = add guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.07. Die set ~DIN 9816 Shape D
A14 subject to alterations Die set DIN 9812 Shape C/CG M .030 .040 .031 M .041 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Available without or with shank thread in top bolster 30 c1 c3 c2 b2 d3 a2 a1 f e B A B A d2 l b1 r 201.11. Section A - A Section B - B Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 d2 d3 e f l r M 201.11.070.050.□□□.□□ 70 x 50 170 70 40 22 50 20 19 110 73 140 - 400 20 20x1.5 201.11.080.063.□□□.□□ 80 x 63 235 103 50 30 80 20 19 140 90 160 - 400 27 20x1.5 201.11.100.063.□□□.□□ 100 x 63 253 103 50 30 80 20 19 158 110 160 - 400 27 20x1.5 201.11.100.080.□□□.□□ 100 x 80 265 120 50 30 80 25 24 165 110 160 - 500 30 20x1.5 201.11.125.080.□□□.□□ 125 x 80 290 120 50 30 80 25 24 190 139 160 - 500 30 20x1.5 201.11.160.080.□□□.□□ 160 x 80 325 120 50 30 80 25 24 225 174 160 - 500 30 20x1.5 201.11.200.080.□□□.□□ 200 x 80 365 120 50 30 80 25 24 265 218 160 - 500 30 20x1.5 201.11.125.100.□□□.□□ 125 x 100 290 140 50 40 90 25 24 190 139 160 - 500 30 24x1.5 201.11.160.100.□□□.□□ 160 x 100 325 140 50 40 90 25 24 225 174 160 - 500 30 24x1.5 201.11.200.100.□□□.□□ 200 x 100 395 140 56 40 90 32 30 280 218 180 - 500 37 24x1.5 201.11.160.125.□□□.□□ 160 x 125 355 165 56 40 90 32 30 240 174 180 - 500 37 24x1.5 201.11.200.125.□□□.□□ 200 x 125 395 165 56 40 90 32 30 280 218 180 - 500 37 24x1.5 201.11.250.125.□□□.□□ 250 x 125 445 165 56 40 90 32 30 330 268 180 - 500 37 24x1.5 201.11.315.125.□□□.□□ 315 x 125 510 165 56 40 90 32 30 395 333 180 - 500 37 24x1.5 201.11.200.160.□□□.□□ 200 x 160 395 200 56 50 100 32 30 280 218 200 - 500 37 30x2 201.11.250.160.□□□.□□ 250 x 160 445 200 56 50 100 32 30 330 268 200 - 500 37 30x2 201.11.250.200.□□□.□□ 250 x 200 496 250 63 50 100 40 38 350 268 224 - 800 48 30x2 201.11.315.200.□□□.□□ 315 x 200 563 250 63 50 100 40 38 417 333 224 - 800 48 30x2 201.11.315.250.□□□.□□ 315 x 250 563 300 63 50 100 40 38 417 333 224 - 800 48 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.11. Die set DIN 9812 Shape C/CG
A15 subject to alterations 45° c4 c3 30 c1 c2 b2 d3 a2 a1 f e d2 b1 r B A B A l c8 201.13. Section A - A Section B - B Die set DIN 9814 Shape C/CG M .034 .054 .035 M .055 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Stripper Steel Steel Order No (part 2) Available without or with shank thread in top bolster Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 c4 c8 d2 d3 e l r M 201.13.080.063.□□□.□□ 80 x 63 235 103 50 30 50 18 14 20 19 140 160 - 400 27 20x1.5 201.13.100.080.□□□.□□ 100 x 80 265 120 50 30 50 22 18 25 24 165 160 - 500 30 20x1.5 201.13.125.100.□□□.□□ 125 x 100 290 140 50 40 60 22 18 25 24 190 160 - 500 30 24x1.5 201.13.160.125.□□□.□□ 160 x 125 355 165 56 40 60 27 18 32 30 240 180 - 500 37 24x1.5 201.13.200.160.□□□.□□ 200 x 160 395 200 56 50 70 27 18 32 30 280 200 - 500 37 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.13. Die set DIN 9814 Shape C/CG
A16 subject to alterations Die set DIN 9819 Shape C/CG M .030 .040 .031 M .041 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Available without or with shank thread in top bolster c2 c3 e f l b2 30 c1 d3 a1 e A B A B a2 d2 r b1 1 201.21. Section B - B Section A - A Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 d2 d3 e e1 f l r M 201.21.080.063.□□□.□□ 80 x 63 120 103 50 30 80 20 19 80 145 73 160 - 400 27 20x1.5 201.21.100.063.□□□.□□ 100 x 63 140 103 50 30 80 20 19 100 157 73 160 - 400 27 20x1.5 201.21.100.080.□□□.□□ 100 x 80 140 120 50 30 80 25 24 100 175 90 160 - 500 30 20x1.5 201.21.125.080.□□□.□□ 125 x 80 165 120 50 30 80 25 24 125 191 90 160 - 500 30 20x1.5 201.21.125.100.□□□.□□ 125 x 100 165 140 50 40 90 25 24 125 206 110 160 - 500 30 24x1.5 201.21.160.100.□□□.□□ 160 x 100 200 140 50 40 90 25 24 160 229 110 160 - 500 30 24x1.5 201.21.200.100.□□□.□□ 200 x 100 240 140 56 40 90 32 30 200 268 110 180 - 500 37 24x1.5 201.21.160.125.□□□.□□ 160 x 125 200 165 56 40 90 32 30 160 259 139 180 - 500 37 24x1.5 201.21.200.125.□□□.□□ 200 x 125 240 165 56 40 90 32 30 200 286 139 180 - 500 37 24x1.5 201.21.250.125.□□□.□□ 250 x 125 290 165 56 40 90 32 30 250 323 139 180 - 500 37 24x1.5 201.21.315.125.□□□.□□ 315 x 125 355 165 56 40 90 32 30 315 375 139 180 - 500 37 24x1.5 201.21.200.160.□□□.□□ 200 x 160 240 200 56 50 100 32 30 200 312 174 200 - 500 37 30x2 201.21.250.160.□□□.□□ 250 x 160 290 200 56 50 100 32 30 250 346 174 200 - 500 37 30x2 201.21.250.200.□□□.□□ 250 x 200 300 250 63 50 100 40 38 250 392 218 224 - 800 48 30x2 201.21.315.200.□□□.□□ 315 x 200 365 250 63 50 100 40 38 315 436 218 224 - 800 48 30x2 201.21.315.250.□□□.□□ 315 x 250 365 300 63 50 100 40 38 315 472 268 224 - 800 48 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.21. Die set DIN 9819 Shape C/CG
A17 subject to alterations e f l c8 c4 b2 30 2c 3c c1 d3 a1 e A B A B a2 d2 r b1 1 201.23. Section B - B Section A - A Die set M .034 .054 .035 M .055 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Stripper Steel Steel Order No (part 2) Available without or with shank thread in top bolster Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 c4 c8 d2 d3 e e1 f l r M 201.23.100.080.□□□.□□ 100 x 80 140 120 50 30 50 22 15 25 24 100 175 98 160 - 500 30 20x1.5 201.23.125.100.□□□.□□ 125 x 100 165 140 50 40 60 22 15 25 24 125 206 118 160 - 500 30 24x1.5 201.23.160.100.□□□.□□ 160 x 100 200 140 50 40 60 22 15 25 24 160 229 118 160 - 500 30 24x1.5 201.23.160.125.□□□.□□ 160 x 125 200 165 56 40 60 27 15 32 30 160 259 148 180 - 500 37 24x1.5 201.23.200.125.□□□.□□ 200 x 125 240 165 56 40 60 27 15 32 30 200 286 148 180 - 500 37 24x1.5 201.23.250.160.□□□.□□ 250 x 160 290 200 56 50 70 27 15 32 30 250 346 184 200 - 500 37 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.23. Die set
A18 subject to alterations Die set M .030 .040 .031 M .041 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Available without or with shank thread in top bolster e1 l 30 c1 3c 2c b e a1 a2 d3 d2 b2 1 A B A B f r 201.26. Section B - B Section A - A Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 d2 d3 e e1 f l r M 201.26.125.100.□□□.□□ 125 x 100 165 140 50 40 90 25 24 125 206 110 160 - 500 30 24x1.5 201.26.160.100.□□□.□□ 160 x 100 200 140 50 40 90 25 24 160 229 110 160 - 500 30 24x1.5 201.26.160.125.□□□.□□ 160 x 125 200 165 56 40 90 32 30 160 259 139 180 - 500 37 24x1.5 201.26.200.125.□□□.□□ 200 x 125 240 165 56 40 90 32 30 200 286 139 180 - 500 37 24x1.5 201.26.200.160.□□□.□□ 200 x 160 240 200 56 50 100 32 30 200 312 174 200 - 500 37 30x2 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.26. Die set
A19 subject to alterations l f 3e b1 b2 30 c3 a2 a1 A B A B r d2 d2 c1 c2 201.31. e1 Section A - A Section B - B Die set DIN 9822 Shape C .030 .040 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Without shank thread in top bolster Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 d2 e1 e3 f l r 201.31.063.050.□□□.□□ 63 x 50 95 84 40 25 50 20 72 77 55 140 - 400 22 201.31.080.063.□□□.□□ 80 x 63 125 105 45 30 60 20 80 92 68 160 - 400 27 201.31.100.063.□□□.□□ 100 x 63 145 105 45 30 60 20 100 92 68 160 - 400 27 201.31.100.080.□□□.□□ 100 x 80 145 130 50 30 70 25 100 112 87 160 - 500 30 201.31.125.080.□□□.□□ 125 x 80 170 130 50 30 70 25 125 112 87 160 - 500 30 201.31.160.080.□□□.□□ 160 x 80 205 130 50 30 70 25 160 112 87 160 - 500 30 201.31.125.100.□□□.□□ 125 x 100 170 150 56 40 90 32 125 140 107 180 - 500 37 201.31.160.100.□□□.□□ 160 x 100 205 150 56 40 90 32 160 140 107 180 - 500 37 201.31.200.100.□□□.□□ 200 x 100 245 150 56 40 90 32 200 140 107 180 - 500 37 201.31.160.125.□□□.□□ 160 x 125 215 180 56 40 90 32 160 165 132 180 - 500 37 201.31.200.125.□□□.□□ 200 x 125 255 180 56 40 90 32 200 165 132 180 - 500 37 201.31.250.125.□□□.□□ 250 x 125 305 180 56 40 90 32 250 165 132 180 - 500 37 201.31.200.160.□□□.□□ 200 x 160 255 225 63 50 120 40 200 210 167 224 - 800 48 201.31.250.160.□□□.□□ 250 x 160 305 225 63 50 120 40 250 210 167 224 - 800 48 201.31.250.200.□□□.□□ 250 x 200 305 270 63 50 120 50 250 260 207 224 - 800 56 201.31.315.250.□□□.□□ 315 x 250 370 320 63 50 120 50 315 310 257 224 - 800 56 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.31. Die set DIN 9822 Shape C
A20 subject to alterations Die set .030 .040 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Without shank thread in top bolster 3c 2c 4c c1 20 e3 b2 e4 b1 f a1 a2 e d2 d2 r e4 l A B A B 201.33. Section B - B Section A - A 201.33. Die set Work area Order No part 1* a1 x b1 a2 b2 c1 c2 c3 c4 d2 e e3 e4 f l r 201.33.063.050.□□□.□□ 63 x 50 116 110 25 25 40 45 16 72 88 74 57 125 - 355 22 201.33.080.060.□□□.□□ 80 x 60 116 117 25 25 40 45 20 72 95 81 62 160 - 400 22 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames
A21 subject to alterations c2 c3 c7 c1 d1 e2 e 3b l 2b 3e d2 d2 a2 r A B A B 201.36. Section B - B Section A - A Die set .030 .040 Guide Elements Sintered Ferrite Guide Bushes Ball Bearing Guides Order No (part 2) Without shank thread in top bolster Work area Order No part 1* d1 a2 b2 b3 c1 c2 c3 c7 d2 e e2 e3 l r 201.36.050.□□□.□□ 50 80 80 65 40 30 50 25 20 66 33 73 125 - 400 20 201.36.063.□□□.□□ 63 94 94 78 45 30 60 25 20 82 41 88 125 - 400 25 201.36.080.□□□.□□ 80 110 110 95 50 30 70 30 25 105 52 107 160 - 500 30 201.36.100.□□□.□□ 100 140 140 120 50 30 70 30 25 125 57 127 160 - 500 30 201.36.125.□□□.□□ 125 166 166 145 56 40 90 30 32 157 73 156 180 - 500 38 201.36.160.□□□.□□ 160 200 200 180 63 50 120 30 40 200 85 185 224 - 800 48 201.36.180.□□□.□□ 180 220 220 200 63 50 120 30 40 224 90 200 224 - 800 48 201.36.200.□□□.□□ 200 250 250 225 63 50 120 30 50 250 95 220 224 - 800 56 201.36.250.□□□.□□ 250 300 300 275 63 50 120 30 50 300 120 270 224 - 800 56 *Order number part 2 = add guide type and guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.36. Die set
A22 subject to alterations Fine blanking die set c7 c7 b1 b1 b2 g e a2 l d3 d2 d1 1 c1 c1 r 2r A B A B 201.39. Section A - A Section B - B Faces front and rear fine machined after assembly – their perfect alignment permits use as datum reference. Work area Order No d1 a2 b1 b2 c1 c7 d2 d3 g e l r1 r2 201.39.100.040.□□ 100 220 50 85 75 22 25 24 60 140 140 - 500 27 6 201.39.125.040.□□ 125 245 62 100 75 25 25 24 80 165 140 - 500 27 6 201.39.160.040.□□ 160 290 80 140 75 25 32 30 80 200 140 - 500 35 6 201.39.200.040.□□ 200 340 100 160 80 30 40 38 90 250 160 - 800 45 8 201.39.250.040.□□ 250 400 125 200 85 32 40 38 100 300 180 - 800 50 10 *Order number part 2 = add guide pillar type/length Order example, see beginning of chapter cast pillar frames 201.39. Fine blanking die set Guide Elements Ball Bearing Guides
A23 subject to alterations All-Steel- and Aluminium Die Sets
A24 2010.□5. 2010.□6. 2010.□7. 2010.□9. l 3e a4 e2 b1 e2 3 b1 1b 1c c2 c4 d1 d1 e1 a2 a1 e4 a2 a1 e1 a2 a1 e1 d2 d2 D e2 a3 a d2 d2 d2 d2 b1 d2 a1 e1 d2 2010. subject to alterations 202.19. 202.19. 2081.3□. 2081.4□. 206.71. Standard Guide Systems Headed Sintered Ferrite Bushes, carbonitrided = .834. Headed Ball Bearing Bushes = .862. Die set without stripper ~DIN 9868/ISO 11415 Description: FIBRO Die Sets offer the choice between sintered ferrite sliding guides and those of the ball bearing type to DIN-ISO.Both come with headed guide bushes. These are seated in push-fit bolster bores and retained there by screw clamps. Execution: Steel: External contours milled, thickness surfaces ground a1 or b1 ≤ 630 = +0.2/+0.4 a1 or b1 > 630 = +0.2/+0.6 Aluminium: External contours sawn, thickness surfaces ground a1 or b1 = +1/+4 Order note: Hole pattern for the screw clamps depends on positioning of working surface: e.g. 2010.49.2520.4.862.1 lengthwise e.g. 2010.49.2520.4.862.2 crosswise Note: On request, Standard Die Sets can also be fitted with any other FIBRO Guide Elements (see die sets to customers’ drawings). FIBRO will furthermore supply die sets with special machining features.
A25 2010. □□ . 2010.□5. 2010.□6. 2010.□7. 2010.□9. a1 ⊗ b1 a2 ⊗ b1 a1 ⊗ a3 a1 ⊗ a4 c1 ± 2c2 ± 2 .834. c4 .862. c4 d1/d2 ⊗ l D e1 e2 e3 e4 2010. .1608. 1. . 160⊗ 80 60⊗ 80 – – 32 32 20 36 19/20 ⊗ 160 39 100 – – – 2010. .1610. 1. . 160 ⊗ 100 60 ⊗ 100 – 160 ⊗ 50 32 32 20 36 19/20 ⊗ 160 39 100 – 70 – 2010. .1612. 1. . 160 ⊗ 125 60 ⊗ 125 – 160 ⊗ 75 32 32 20 36 19/20 ⊗ 160 39 100 – 95 – 2010. .1616. 1. . 160 ⊗ 160 60 ⊗ 160 160 ⊗ 60 160 ⊗ 110 32 32 20 36 19/20 ⊗ 160 39 100 100 130 103 2010. .2010. 1. . 200 ⊗ 100 70 ⊗ 100 – – 40 40 36 56 24/25 ⊗ 180 46 120 – – – 2010. .2010. 2. . 200 ⊗ 100 70 ⊗ 100 – – 40 32 36 56 24/25 ⊗ 180 46 120 – – – 2010. .2010. 3. . 200 ⊗ 100 70 ⊗ 100 – – 32 40 36 56 24/25 ⊗ 180 46 120 – – – 2010. .2010. 4. . 200 ⊗ 100 70 ⊗ 100 – – 32 32 36 56 24/25 ⊗ 180 46 120 – – – 2010. .2012. 1. . 200 ⊗ 125 70 ⊗ 125 – 200 ⊗ 60 40 40 36 56 24/25 ⊗ 180 46 120 – 85 – 2010. .2012. 2. . 200 ⊗ 125 70 ⊗ 125 – 200 ⊗ 60 40 32 36 56 24/25 ⊗ 180 46 120 – 85 – 2010. .2012. 3. . 200 ⊗ 125 70 ⊗ 125 – 200 ⊗ 60 32 40 36 56 24/25 ⊗ 180 46 120 – 85 – 2010. .2012. 4. . 200 ⊗ 125 70 ⊗ 125 – 200 ⊗ 60 32 32 36 56 24/25 ⊗ 180 46 120 – 85 – 2010. .2016. 1. . 200 ⊗ 160 70 ⊗ 160 – 200 ⊗ 95 40 40 36 56 24/25 ⊗ 180 46 120 – 120 – 2010. .2016. 2. . 200 ⊗ 160 70 ⊗ 160 – 200 ⊗ 95 40 32 36 56 24/25 ⊗ 180 46 120 – 120 – 2010. .2016. 3. . 200 ⊗ 160 70 ⊗ 160 – 200 ⊗ 95 32 40 36 56 24/25 ⊗ 180 46 120 – 120 – 2010. .2016. 4. . 200 ⊗ 160 70 ⊗ 160 – 200 ⊗ 95 32 32 36 56 24/25 ⊗ 180 46 120 – 120 – 2010. .2020. 1. . 200 ⊗ 200 70 ⊗ 200 200 ⊗ 70 200 ⊗ 135 40 40 36 56 24/25 ⊗ 180 46 120 120 160 123 2010. .2020. 2. . 200 ⊗ 200 70 ⊗ 200 200 ⊗ 70 200 ⊗ 135 40 32 36 56 24/25 ⊗ 180 46 120 120 160 123 2010. .2020. 3. . 200 ⊗ 200 70 ⊗ 200 200 ⊗ 70 200 ⊗ 135 32 40 36 56 24/25 ⊗ 180 46 120 120 160 123 2010. .2020. 4. . 200 ⊗ 200 70 ⊗ 200 200 ⊗ 70 200 ⊗ 135 32 32 36 56 24/25 ⊗ 180 46 120 120 160 123 2010. .2512. 1. . 250 ⊗ 125 120 ⊗ 125 – 250 ⊗ 60 40 40 36 56 24/25 ⊗ 180 46 170 – 85 – 2010. .2512. 2. . 250 ⊗ 125 120 ⊗ 125 – 250 ⊗ 60 40 32 36 56 24/25 ⊗ 180 46 170 – 85 – 2010. .2512. 3. . 250 ⊗ 125 120 ⊗ 125 – 250 ⊗ 60 32 40 36 56 24/25 ⊗ 180 46 170 – 85 – 2010. .2512. 4. . 250 ⊗ 125 120 ⊗ 125 – 250 ⊗ 60 32 32 36 56 24/25 ⊗ 180 46 170 – 85 – 2010. .2516. 1. . 250 ⊗ 160 120 ⊗ 160 – 250 ⊗ 95 40 40 36 56 24/25 ⊗ 180 46 170 – 120 – 2010. .2516. 2. . 250 ⊗ 160 120 ⊗ 160 – 250 ⊗ 95 40 32 36 56 24/25 ⊗ 180 46 170 – 120 – 2010. .2516. 3. . 250 ⊗ 160 120 ⊗ 160 – 250 ⊗ 95 32 40 36 56 24/25 ⊗ 180 46 170 – 120 – 2010. .2516. 4. . 250 ⊗ 160 120 ⊗ 160 – 250 ⊗ 95 32 32 36 56 24/25 ⊗ 180 46 170 – 120 – 2010. .2520. 1. . 250 ⊗ 200 120 ⊗ 200 250 ⊗ 70 250 ⊗ 135 40 40 36 56 24/25 ⊗ 180 46 170 120 160 173 2010. .2520. 2. . 250 ⊗ 200 120 ⊗ 200 250 ⊗ 70 250 ⊗ 135 40 32 36 56 24/25 ⊗ 180 46 170 120 160 173 2010. .2520. 3. . 250 ⊗ 200 120 ⊗ 200 250 ⊗ 70 250 ⊗ 135 32 40 36 56 24/25 ⊗ 180 46 170 120 160 173 2010. .2520. 4. . 250 ⊗ 200 120 ⊗ 200 250 ⊗ 70 250 ⊗ 135 32 32 36 56 24/25 ⊗ 180 46 170 120 160 173 2010. .2525. 1. . 250 ⊗ 250 120 ⊗ 250 250 ⊗ 120 250 ⊗ 185 40 40 36 56 24/25 ⊗ 180 46 170 170 210 173 2010. .2525. 2. . 250 ⊗ 250 120 ⊗ 250 250 ⊗ 120 250 ⊗ 185 40 32 36 56 24/25 ⊗ 180 46 170 170 210 173 2010. .2525. 3. . 250 ⊗ 250 120 ⊗ 250 250 ⊗ 120 250 ⊗ 185 32 40 36 56 24/25 ⊗ 180 46 170 170 210 173 2010. .2525. 4. . 250 ⊗ 250 120 ⊗ 250 250 ⊗ 120 250 ⊗ 185 32 32 36 56 24/25 ⊗ 180 46 170 170 210 173 2010. .3116. 1. . 315 ⊗ 160 165 ⊗ 160 – 315 ⊗ 85 50 50 45 63 30/32 ⊗ 200 53 225 – 115 – 2010. .3116. 2. . 315 ⊗ 160 165 ⊗ 160 – 315 ⊗ 85 50 40 45 63 30/32 ⊗ 200 53 225 – 115 – 2010. .3116. 3. . 315 ⊗ 160 165 ⊗ 160 – 315 ⊗ 85 40 50 45 63 30/32 ⊗ 200 53 225 – 115 – 2010. .3116. 4. . 315 ⊗ 160 165 ⊗ 160 – 315 ⊗ 85 40 40 45 63 30/32 ⊗ 200 53 225 – 115 – 2010. .3120. 1. . 315 ⊗ 200 165 ⊗ 200 315 ⊗ 50 315 ⊗ 125 50 50 45 63 30/32 ⊗ 200 53 225 110 155 228 2010. .3120. 2. . 315 ⊗ 200 165 ⊗ 200 315 ⊗ 50 315 ⊗ 125 50 40 45 63 30/32 ⊗ 200 53 225 110 155 228 2010. .3120. 3. . 315 ⊗ 200 165 ⊗ 200 315 ⊗ 50 315 ⊗ 125 40 50 45 63 30/32 ⊗ 200 53 225 110 155 228 2010. .3120. 4. . 315 ⊗ 200 165 ⊗ 200 315 ⊗ 50 315 ⊗ 125 40 40 45 63 30/32 ⊗ 200 53 225 110 155 228 2010. .3125. 1. . 315 ⊗ 250 165 ⊗ 250 315 ⊗ 100 315 ⊗ 175 50 50 45 63 30/32 ⊗ 200 53 225 160 205 228 2010. .3125. 2. . 315 ⊗ 250 165 ⊗ 250 315 ⊗ 100 315 ⊗ 175 50 40 45 63 30/32 ⊗ 200 53 225 160 205 228 2010. .3125. 3. . 315 ⊗ 250 165 ⊗ 250 315 ⊗ 100 315 ⊗ 175 40 50 45 63 30/32 ⊗ 200 53 225 160 205 228 2010. .3125. 4. . 315 ⊗ 250 165 ⊗ 250 315 ⊗ 100 315 ⊗ 175 40 40 45 63 30/32 ⊗ 200 53 225 160 205 228 2010. .3131. 1. . 315 ⊗ 315 165 ⊗ 315 315 ⊗ 165 315 ⊗ 240 50 50 45 63 30/32 ⊗ 200 53 225 225 270 228 2010. .3131. 2. . 315 ⊗ 315 165 ⊗ 315 315 ⊗ 165 315 ⊗ 240 50 40 45 63 30/32 ⊗ 200 53 225 225 270 228 2010. .3131. 3. . 315 ⊗ 315 165 ⊗ 315 315 ⊗ 165 315 ⊗ 240 40 50 45 63 30/32 ⊗ 200 53 225 225 270 228 2010. .3131. 4. . 315 ⊗ 315 165 ⊗ 315 315 ⊗ 165 315 ⊗ 240 40 40 45 63 30/32 ⊗ 200 53 225 225 270 228 2010. .4020. 1. . 400 ⊗ 200 250 ⊗ 200 400 ⊗ 50 400 ⊗ 125 50 50 45 63 30/32 ⊗ 200 53 310 110 155 313 2010. .4020. 2. . 400 ⊗ 200 250 ⊗ 200 400 ⊗ 50 400 ⊗ 125 50 40 45 63 30/32 ⊗ 200 53 310 110 155 313 2010. .4020. 3. . 400 ⊗ 200 250 ⊗ 200 400 ⊗ 50 400 ⊗ 125 40 50 45 63 30/32 ⊗ 200 53 310 110 155 313 2010. .4020. 4. . 400 ⊗ 200 250 ⊗ 200 400 ⊗ 50 400 ⊗ 125 40 40 45 63 30/32 ⊗ 200 53 310 110 155 313 2010. .4025. 1. . 400 ⊗ 250 250 ⊗ 250 400 ⊗ 100 400 ⊗ 175 50 50 45 63 30/32 ⊗ 200 53 310 160 205 313 2010. .4025. 2. . 400 ⊗ 250 250 ⊗ 250 400 ⊗ 100 400 ⊗ 175 50 40 45 63 30/32 ⊗ 200 53 310 160 205 313 2010. .4025. 3. . 400 ⊗ 250 250 ⊗ 250 400 ⊗ 100 400 ⊗ 175 40 50 45 63 30/32 ⊗ 200 53 310 160 205 313 2010. .4025. 4. . 400 ⊗ 250 250 ⊗ 250 400 ⊗ 100 400 ⊗ 175 40 40 45 63 30/32 ⊗ 200 53 310 160 205 313 2010. .4031. 1. . 400 ⊗ 315 250 ⊗ 315 400 ⊗ 165 400 ⊗ 240 50 50 45 63 30/32 ⊗ 200 53 310 225 270 313 2010. .4031. 2. . 400 ⊗ 315 250 ⊗ 315 400 ⊗ 165 400 ⊗ 240 50 40 45 63 30/32 ⊗ 200 53 310 225 270 313 subject to alterations Die set without stripper ~DIN 9868/ISO 11415 Type Order No external dimensions Work area crosswise Work area along Work area along Ordering Code (principle): Position of work area: 2 Guide system: Headed ball bearing bushes Thickness combinations P: c1 - c2 Ext. dimensions: a1 = 400 x b1 = 250 Type: Position of guide elements Material: 4 = Steel, 6 = Aluminium Standard Die sets 2010 . 4 5 . 4025 . 1 . 862 . 2
A26 2010.□5. 2010.□6. 2010.□7. 2010.□9. l 3e a4 e2 b1 e2 3 b1 1b 1c c2 c4 d1 d1 e1 a2 a1 e4 a2 a1 e1 a2 a1 e1 d2 d2 D e2 a3 a d2 d2 d2 d2 b1 d2 a1 e1 d2 2010. subject to alterations 202.19. 202.19. 2081.3□. 2081.4□. 206.71. Standard Guide Systems Headed Sintered Ferrite Bushes, carbonitrided = .834. Headed Ball Bearing Bushes = .862. Die set without stripper ~DIN 9868/ISO 11415 Description: FIBRO Die Sets offer the choice between sintered ferrite sliding guides and those of the ball bearing type to DIN-ISO.Both come with headed guide bushes. These are seated in push-fit bolster bores and retained there by screw clamps. Execution: Steel: External contours milled, thickness surfaces ground a1 or b1 ≤ 630 = +0.2/+0.4 a1 or b1 > 630 = +0.2/+0.6 Aluminium: External contours sawn, thickness surfaces ground a1 or b1 = +1/+4 Order note: Hole pattern for the screw clamps depends on positioning of working surface: e.g. 2010.49.2520.4.865.1 lengthwise e.g. 2010.49.2520.4.865.2 crosswise Note: On request, Standard Die Sets can also be fitted with any other FIBRO Guide Elements (see die sets to customers’ drawings). FIBRO will furthermore supply die sets with special machining features.
A27 2010.□5. 2010.□6. 2010.□7. 2010.□9. 2010. □□ . a1 ⊗ b1 a2 ⊗ b1 a1 ⊗ a3 a1 ⊗ a4 c1 ± 2c2 ± 2 .834. c4 .862. c4 d1/d2 ⊗ l D e1 e2 e3 e4 2010. .4031. 3. . 400 x 315 250 x 315 400 x 165 400 x 240 40 50 45 63 30/32 x 200 53 310 225 270 313 2010. .4031. 4. . 400 x 315 250 x 315 400 x 165 400 x 240 40 40 45 63 30/32 x 200 53 310 225 270 313 2010. .4040. 1. . 400 x 400 250 x 400 400 x 250 400 x 325 50 50 45 63 30/32 x 200 53 310 310 355 313 2010. .4040. 2. . 400 x 400 250 x 400 400 x 250 400 x 325 50 40 45 63 30/32 x 200 53 310 310 355 313 2010. .4040. 3. . 400 x 400 250 x 400 400 x 250 400 x 325 40 50 45 63 30/32 x 200 53 310 310 355 313 2010. .4040. 4. . 400 x 400 250 x 400 400 x 250 400 x 325 40 40 45 63 30/32 x 200 53 310 310 355 313 2010. .5025. 1. . 500 x 250 330 x 250 500 x 80 500 x 165 50 50 45 71 38/40 x 200 63 400 150 200 403 2010. .5025. 2. . 500 x 250 330 x 250 500 x 80 500 x 165 50 40 45 71 38/40 x 200 63 400 150 200 403 2010. .5025. 3. . 500 x 250 330 x 250 500 x 80 500 x 165 40 50 45 71 38/40 x 200 63 400 150 200 403 2010. .5025. 4. . 500 x 250 330 x 250 500 x 80 500 x 165 40 40 45 71 38/40 x 200 63 400 150 200 403 2010. .5031. 1. . 500 x 315 330 x 315 500 x 145 500 x 230 50 50 45 71 38/40 x 200 63 400 215 265 403 2010. .5031. 2. . 500 x 315 330 x 315 500 x 145 500 x 230 50 40 45 71 38/40 x 200 63 400 215 265 403 2010. .5031. 3. . 500 x 315 330 x 315 500 x 145 500 x 230 40 50 45 71 38/40 x 200 63 400 215 265 403 2010. .5031. 4. . 500 x 315 330 x 315 500 x 145 500 x 230 40 40 45 71 38/40 x 200 63 400 215 265 403 2010. .5040. 1. . 500 x 400 330 x 400 500 x 230 500 x 315 50 50 45 71 38/40 x 200 63 400 300 350 403 2010. .5040. 2. . 500 x 400 330 x 400 500 x 230 500 x 315 50 40 45 71 38/40 x 200 63 400 300 350 403 2010. .5040. 3. . 500 x 400 330 x 400 500 x 230 500 x 315 40 50 45 71 38/40 x 200 63 400 300 350 403 2010. .5040. 4. . 500 x 400 330 x 400 500 x 230 500 x 315 40 40 45 71 38/40 x 200 63 400 300 350 403 2010. .5050. 1. . 500 x 500 330 x 500 500 x 330 500 x 415 50 50 45 71 38/40 x 200 63 400 400 450 403 2010. .5050. 2. . 500 x 500 330 x 500 500 x 330 500 x 415 50 40 45 71 38/40 x 200 63 400 400 450 403 2010. .5050. 3. . 500 x 500 330 x 500 500 x 330 500 x 415 40 50 45 71 38/40 x 200 63 400 400 450 403 2010. .5050. 4. . 500 x 500 330 x 500 500 x 330 500 x 415 40 40 45 71 38/40 x 200 63 400 400 450 403 2010. .6331. 1. . 630 x 315 430 x 315 630 x 115 630 x 215 63 63 50 80 48/50 x 250 77 510 195 255 513 2010. .6331. 2. . 630 x 315 430 x 315 630 x 115 630 x 215 63 50 50 80 48/50 x 250 77 510 195 255 513 2010. .6331. 3. . 630 x 315 430 x 315 630 x 115 630 x 215 50 63 50 80 48/50 x 224 77 510 195 255 513 2010. .6331. 4. . 630 x 315 430 x 315 630 x 115 630 x 215 50 50 50 80 48/50 x 224 77 510 195 255 513 2010. .6340. 1. . 630 x 400 430 x 400 630 x 200 630 x 300 63 63 50 80 48/50 x 250 77 510 280 340 513 2010. .6340. 2. . 630 x 400 430 x 400 630 x 200 630 x 300 63 50 50 80 48/50 x 250 77 510 280 340 513 2010. .6340. 3. . 630 x 400 430 x 400 630 x 200 630 x 300 50 63 50 80 48/50 x 224 77 510 280 340 513 2010. .6340. 4. . 630 x 400 430 x 400 630 x 200 630 x 300 50 50 50 80 48/50 x 224 77 510 280 340 513 2010. .6350. 1. . 630 x 500 430 x 500 630 x 300 630 x 400 63 63 50 80 48/50 x 250 77 510 380 440 513 2010. .6350. 2. . 630 x 500 430 x 500 630 x 300 630 x 400 63 50 50 80 48/50 x 250 77 510 380 440 513 2010. .6350. 3. . 630 x 500 430 x 500 630 x 300 630 x 400 50 63 50 80 48/50 x 224 77 510 380 440 513 2010. .6350. 4. . 630 x 500 430 x 500 630 x 300 630 x 400 50 50 50 80 48/50 x 224 77 510 380 440 513 2010. .6363. 1. . 630 x 630 430 x 630 630 x 430 630 x 530 63 63 50 80 48/50 x 250 77 510 510 570 513 2010. .6363. 2. . 630 x 630 430 x 630 630 x 430 630 x 530 63 50 50 80 48/50 x 250 77 510 510 570 513 2010. .6363. 3. . 630 x 630 430 x 630 630 x 430 630 x 530 50 63 50 80 48/50 x 224 77 510 510 570 513 2010. .6363. 4. . 630 x 630 430 x 630 630 x 430 630 x 530 50 50 50 80 48/50 x 224 77 510 510 570 513 2010. .7140. 1. . 710 x 400 510 x 400 710 x 200 710 x 300 63 63 50 80 48/50 x 250 77 590 280 340 593 2010. .7140. 2. . 710 x 400 510 x 400 710 x 200 710 x 300 63 50 50 80 48/50 x 250 77 590 280 340 593 2010. .7140. 3. . 710 x 400 510 x 400 710 x 200 710 x 300 50 63 50 80 48/50 x 224 77 590 280 340 593 2010. .7140. 4. . 710 x 400 510 x 400 710 x 200 710 x 300 50 50 50 80 48/50 x 224 77 590 280 340 593 2010. .7150. 1. . 710 x 500 510 x 500 710 x 300 710 x 400 63 63 50 80 48/50 x 250 77 590 380 440 593 2010. .7150. 2. . 710 x 500 510 x 500 710 x 300 710 x 400 63 50 50 80 48/50 x 250 77 590 380 440 593 2010. .7150. 3. . 710 x 500 510 x 500 710 x 300 710 x 400 50 63 50 80 48/50 x 224 77 590 380 440 593 2010. .7150. 4. . 710 x 500 510 x 500 710 x 300 710 x 400 50 50 50 80 48/50 x 224 77 590 380 440 593 2010. .7163. 1. . 710 x 630 510 x 630 710 x 430 710 x 530 63 63 50 80 48/50 x 250 77 590 510 570 593 2010. .7163. 2. . 710 x 630 510 x 630 710 x 430 710 x 530 63 50 50 80 48/50 x 250 77 590 510 570 593 2010. .7163. 3. . 710 x 630 510 x 630 710 x 430 710 x 530 50 63 50 80 48/50 x 224 77 590 510 570 593 2010. .7163. 4. . 710 x 630 510 x 630 710 x 430 710 x 530 50 50 50 80 48/50 x 224 77 590 510 570 593 2010. .8040. 1. . 800 x 400 600 x 400 800 x 200 800 x 300 63 63 50 80 48/50 x 250 77 680 280 340 683 2010. .8040. 2. . 800 x 400 600 x 400 800 x 200 800 x 300 63 50 50 80 48/50 x 250 77 680 280 340 683 2010. .8040. 3. . 800 x 400 600 x 400 800 x 200 800 x 300 50 63 50 80 48/50 x 224 77 680 280 340 683 2010. .8040. 4. . 800 x 400 600 x 400 800 x 200 800 x 300 50 50 50 80 48/50 x 224 77 680 280 340 683 2010. .8050. 1. . 800 x 500 600 x 500 800 x 300 800 x 400 63 63 50 80 48/50 x 250 77 680 380 440 683 2010. .8050. 2. . 800 x 500 600 x 500 800 x 300 800 x 400 63 50 50 80 48/50 x 250 77 680 380 440 683 2010. .8050. 3. . 800 x 500 600 x 500 800 x 300 800 x 400 50 63 50 80 48/50 x 224 77 680 380 440 683 2010. .8050. 4. . 800 x 500 600 x 500 800 x 300 800 x 400 50 50 50 80 48/50 x 224 77 680 380 440 683 2010. .8063. 1. . 800 x 630 600 x 630 800 x 430 800 x 530 63 63 50 80 48/50 x 250 77 680 510 570 683 2010. .8063. 2. . 800 x 630 600 x 630 800 x 430 800 x 530 63 50 50 80 48/50 x 250 77 680 510 570 683 2010. .8063. 3. . 800 x 630 600 x 630 800 x 430 800 x 530 50 63 50 80 48/50 x 224 77 680 510 570 683 2010. .8063. 4. . 800 x 630 600 x 630 800 x 430 800 x 530 50 50 50 80 48/50 x 224 77 680 510 570 683 subject to alterations Die set without stripper ~DIN 9868/ISO 11415 Type Order No external dimensions Work area crosswise Work area along Work area along Ordering Code (principle): Position of work area: 2 Guide system: Headed ball bearing bushes Thickness combinations P: c1 - c2 Ext. dimensions: a1 = 400 x b1 = 250 Type: Position of guide elements Material: 4 = Steel, 6 = Aluminium Standard Die sets 2010 . 4 5 . 4025 . 1 . 862 . 2
